090 3/4" Elbow FF STANDARD
Fittings of brass CW617N. Fittings are specified for joining of threaded according to ISO 228-1. Design: without surface treatment.
| Your price | 73,69 Kč |
| Your price without VAT | 60,90 Kč |
In stock (1459 pcs)Not in stock
| Unit: | pcs |
| Code 2: | 031.MMS.090.020 |
| EAN: | 8592018404441 |
| Warranty: | 2 YEARS |
| Norms: | ČSN EN 10242, ČSN ISO 7-1 |
| Certificates: | B-02228-20 |
We recommend
Description
Thread brass fitting, type - elbow 90 ° with pipe threads inner x inner, without surface treatment. Connecting threads G are parallel for join not sealing on threads according ISO 228-1. Produced according EN 1254-4.
Using:
Fittings are used to transport water, drinking water, air, non-abrasive and aggressive substances with maximum working pressure of 1.6 MPa at a temperature of fluid from 0 ° C to 120 ° C, medium can not freeze.
Media
Videos
Other
090 3/4" Elbow black FF
FC09034
33,76 Kč / pcs with VAT
In stock (23665 pcs)Not in stock
Fitting of malleable cast iron B300-06. Fittings are specified for joining of threaded according to ISO 7-1. Design is black.
090 3/4" Elbow galv. FF
FP09034
36,54 Kč / pcs with VAT
In stock (34659 pcs)Not in stock
Fitting of malleable cast iron B300-06. Fittings are specified for joining of threaded according to ISO 7-1. Design: galvanized. Zinc coating thickness of 70 microns is generated by hot dip galvanizing
090 3/4" (26,9mm) Elbow steel
FOC09034
25,26 Kč / pcs with VAT
In stock (0 pcs)Not in stock
Fitting of carbon stell S235. Type 3D - Elbow 90°: radius of curvature R≈1,5D. Supplied in black state with thin layer of conservative oil.
